3.2 Device Connections
1 2
Fig. 2: Precision balance (rear view)
Pos . Name
1 Access switch
2 Power supply
3 PC-USB
4 USB
5 RS232
connection
6 Slot
3 4 5 6
Description
Protects the device from
changes to the device
settings. Is sealed for
conformity-assessed
devices.
Connection for power supply
to the device
USB-C connection, for
connection to a PC
USB-C connection, for
connection to a printer, USB
stick, FTDI cable, or a second
display.
9-pin, for connection to a
printer, PC, or a second
display
For attaching an anti-theft
device, e.g., a Kensington
lock
3.3 Weighing Pan and Associated
Components
1
2
3
Fig. 3: Analytical balance with analytical draft shield and precision
balance with analytical draft shield (example)
Pos . Name
1 Weighing pan
2 Shield disk
3.4 Conformity-assessed Devices
Some settings of conformity-assessed models are
protected against user changes, e.g., external calibration
or the "Safety level" in the "Weighing" menu. This
measure is intended to ensure the suitability of the
devices for use in legal metrology.
Entris II Advanced Line Operating Instructions
®
Device Description
1
2
Description
Only with analytical
balances
