Operating Concept
4 Operating Concept
4.1 Operating Display
1 2
5
Fig. 4: Operating display (example)
Pos . Name Description
1 Toolbar
2 Metrological
data
3 Function bar
4 Application − Shows the selected
toolbar
− Used to access
5 Main menu Shows the available menus
and applications.
12 Entris II Advanced Line Operating Instructions
®
3
4
application.
application-specific
parameters.
4.2 Weighing Range Display
4
Fig. 5: Weighing range display (example)
Pos . Name Description
1 Measured Displays the current measured
value value.
2 User Shows the logged-in user.
3 Bar graph Displays the measured value as
a percentage of weighing
capacity utilization.
4 Time / date
1
2
3
