5.2 Explanation of the display
A - Indicates the day of the week.
B - The current clock time is displayed here.
C - Indicates the temperature (°C) measured.
D - Indicates the number of minutes before the overtime timer function is switched off again and
the PinTherm Infra Connect adjusts to the night-time temperature.
E - Indicates whether the PinTherm Infra Connect is in the day-time (DAY) or night-time
position (NIGHT) and is adjusted based on the day or night-time temperature.
F - Whenever the high/low function is set to automatic in the menu, this is displayed here
(1K, 2K of 3K). If the modulating control is switched on, MOD is displayed here.
5.3 Initial commissioning of the PinTherm Infra Connect
When you set the voltage on the PinTherm Infra Connect for the first time, you will be asked to
select the language required and then to set the time and date (language options: NL, EN, DE, FR,
PL, RO). The PinTherm Infra Connect then goes back to the main screen and the "heating" and
"high" function is switched on.
SELECT LANGUAGE
ENGLISH
Language options: NL, EN, DE, FR, PL, RO.
8
A
MON 08:01
1K DAY
F
select the desired
language
B
16°C
X:060
E
SAT 01-01-2006
00:00:00
OK
changes the
ashing digit
to go one digit up
MON 08:00
DAY
C
D
OK
16°C
