Mark PinTherm Infra Connect Technisches Handbuch Seite 2

Read through this document before you
begin installation and commissioning
Incorrect installation, adjustment, alteration, repair or maintenance work may lead to material
damage or injury. All work must be carried out by certified, qualified professionals. If the
appliance is not positioned in accordance with the instructions, the warranty shall be rendered
void. This appliance is not intended for use by children or persons with a physical, sensory or
mental handicap, or who lack the required experience or expertise, unless they are supervised
or have been instructed in the use of the appliance by somebody who is responsible for their
safety. Children must be supervised to ensure that they do not play with the appliance.
1.0 Contents
2.0 General
2.1 Subject to modifications
2.2 General warnings
3.0 Technical specifications
3.1 PinTherm Infra Connect technical details
3.2 Technical details for external globe sensor / room sensor
3.3 External globe sensor / room sensor resistance table
3.4 PinTherm Infra Connect factory settings
4.0 Installation
4.1 General
4.2 PinTherm Infra Connect assembly
4.3 Assembly of black bulb sensor
Warning!
page 4
page 4
page 4
page 5
page 5
page 5
page 6
page 6
page 6
