Mark PinTherm Infra Connect Technisches Handbuch Seite 13

5.16 Modbus
MODBUS
select
Modbus RTU: Slave ID adjustable 1 - 247 (factory setting: I)
Modbus TCP/IP: Slave ID setting 255
For more information see chapter 8.
* For the PinTherm Infra Connect the Modbus setting must always be "Slave".
5.17 Network Info
NETWORK INFO
select
Display set IP address.
WiFi IP / MAC only available for PinTherm Infra Connect thermostats with a WiFi module (article
no. 3003870). In that case, the password for connecting to WiFi can also be found in this menu
(see chapter 6).
5.18 IP settings
IP SETTINGS
select
IP ADDRESS
192.168.001.100
DHCP - automatic assignment IP address
Static - set fixed IP address
SUBnet Mask
MODBUS MODE
SLAVE
OK
change setting*
ETHERNET IP
NOT CONNECTED
OK
WIFI IP
123.45.67.89
OK
changes the
flashing digit
to go one digit up
MODBUS SLAVE ID
001
OK
changes the
flashing digit
to go one digit up
ETHERNET MAC
FCC23D578598
OK
WIFI MAC
C0EE40B0554A
OK
IP MODE
STATIQ
change setting
SUBNET MASK
255.255.255.000
changes the
flashing digit
to go one digit up
EN
OK
back to the
menu
OK
back to the
menu
OK
OK
back to the
menu
