• Pollution level
• Switch contact(s)*
• Temperature setting
• Overtime timer
• Calibration
• High/low switching
• Sensor
• Language options
• Fuse
* The relay contacts are functional switches, not safety switches.
3.2 Technical details external globe sensor / room sensor
• Type name
• Item number
• Resistance
• Dimensions
• Weight
• Electrical connection
• Degree of protection
3.3 Resistance chart external globe sensor / room sensor
-15°C -10°C
32.937kΩ 25.217kΩ 19.392kΩ
20°C 25°C
5.855kΩ 4.700kΩ
3.4 Factory settings PinTherm Infra Connect
• Menu code
• Switching times
• Room temperature
• Calibration
• High/low adjustment
• High/low switching
• Modulation
• Modbus
: 2
: Heating:230Vac/16A (4A)
Others: 230Vac/10A (2,5A)
: 0 until 39°C per 1°C adjustable
: adjustable 1, 2 or 3 hours (060, 120, 180)
: adjustable from -3.5°C until +3.5°C
: At temperature 1K, 2K, 3K or manual
The PinTherm Infra Connect always starts 20 min at high
when heat is requested
: external globe s(06 29 087)
external room sensor (06 29 086) (Tanner MDE)
: NL/EN/DE/FR/PL/RO
: 6A
External globe sensor
: RSTF NTC4,7K
: 06 29 087
: NTC 4K7
: 79 x 81 x 26mm (l x w x h)
: 46 gram
: 0.75 -1.5mm²
: IP-30
-5°C 0°C
15.040kΩ 11.743kΩ
30°C 35°C
3.777kΩ 3.071kΩ
: 1000
: MON, TUE, WED, THUR, FRI 07:30-17:30hrs
SAT, SUN 00:00-00:00 hrs
: Day-time temperature 18°C
Night-time temperature 08°C
: +0.0
: Manual
: PinTherm Infra Connect always starts 20 min. at high when
heat is requested, regardless if the heat request disappears
during this time.
: OFF
: Slave ID 001
External room sensor
: RSTF NTC4,7K
: 06 29 086
: NTC 4K7
: 79 x 81 x 26mm (l x w x h)
: 46 gram
: 0.75 -1.5mm²
: IP-30
5°C 10°C
9.241kΩ
40°C 45°C
2.512kΩ 2.066kΩ
15°C
7.330kΩ
50°C
1.709kΩ
