Mark PinTherm Infra Connect Technisches Handbuch Seite 16

You can enter the WiFi login details in the Network tab.
Note: You may need to disable mobile internet on your phone to connect to the above network.
4. After the 3 minutes (or 10 minutes when someone is connected to the PinTherm AP) are up,
the WiFi network PinTherm AP will stop and the PinTherm will try to connect to a WiFi network
again for 30 seconds, after which the procedure will repeat itself. This will continue until the con-
nection is successful.
6.2 Registering a PinTherm with a new Cloud account
Follow the steps below to register a PinTherm device in the cloud.
1. Open an internet browser on your PC or phone and navigate to
https://pintherm.mkonnect.nl/Login.
2. On the Login webpage, click on "Create account."
3. On the "Link Device" page, enter the device code and click the "Lookup device" button. The
device code can be found on the label attached to the outside of the PinTherm, as shown below.
0123-A4-BC5-67890
90-240VAC, 1-phase,
47-63Hz, max 9W
Alternatively, you can enter the device code by scanning the
QR code. To scan the QR code, press the QR code button.
4. If the PinTherm can be found, a new input field will ap-
pear. In this field, you must enter an activation code. This
activation code is sent from the cloud to the PinTherm and
must be retrieved via the PinTherm's display (see the image
below). Note: The activation code is time-limited.
MON 08:01
select
DAY
16
Mark Climate Technology
Beneden Verlaat 87-89
9645 BM Veendam
The Netherlands
www.mark.nl
PinTherm Infra Connect
For further information refer
to the manual
16°C
ENTER MENU CODE
0000
ACTIVITATIONCODE
1XX2XX3XX4XX
OK OK
back to the
menu
