Mark PinTherm Infra Connect Technisches Handbuch Seite 118

[3]
MARK PinTherm Infra Connect
+ - PE PE N L
1112
1
Rx
2
1 2
TT
06 29 087
PE
230Vac / 50Hz
[4]
MARK PinTherm Infra Connect 06 29 109
+ - PE PE N L
1112
1
Rx
2
1 2
TT
06 29 087
PE
230Vac / 50Hz
WS
Isolator switch
EN
Reparatur schalter
DE
L'interrupteur de proximité
FR
Werkschakelaar
NL
Wyłacznik serwisowy
PL
RO Switch pentru izolare
118
06 29 109
L 3 1 2 4 N 13 14
WS
2 4
1 3
6A
N L
L 3 1 2 4 N 13 14
WS
2 4
1 3
6A
N L
TT
Black bulb sensor
Schwarze kugel fühler
Capteur globe noir
Zwarte bol voeler
Czujnik Czarna kula
Senzor glob
INFRA 10/15/20/30/40/50 h/l
INFRA 10/15/20/30/40/50 h/l
Max. 10 Infra
M1
Extraction fan
Abluft ventilator
Ventilateur de
Afzuigventilator
Wentilator wyciagowy Wysoko/nisko
Ventilator extractie
Connector
230Vac
1
2
N
3
TH-0629109 / 220 / V10
Connector
230Vac
1
2
Infra 1
N
3
1
2
Infra 2
N
3
TH-0629109 / 255 / V10
h/l
High/low
2-Stufen
Haut/bas
Hoog/laag
Înalt/grav
