Settings menu, fig. 10
Underfloor heating*. Start or stop the underfloor heating. Choose con-
tinuous operation of the underfloor heating by activating "Continuous".
Engine pre-heat*. Warm the engine with the Alde heating system. Start
or stop the function, choose start time and for how long the engine
should be warmed.
Settings menu, fig. 11
EisEx*, defroster for gas regulator. Prevents ice forming in the reg-
ulator during winter. Start or stop the function and choose if EisEx
automatically should start when it is cold.
Delayed start, automatic start for the boiler. Start or stop the function,
choose start and stop time. For the function to work the boiler must be
turned off.
External start. The function is used to start the boiler from outside.
When external start is activated the panel should be shut off. External
start has three settings: Off, External start and 230 V.
Off. The function is off.
External start*. The function is used when starting the boiler with ex-
ternal start, by jumping the connector "Ext Start" on the boiler's PCB.
When the function External Start has been activated the control panel
shall be turned off but 12 V shall still be connected.
230 V. The function is used to start the boiler when 230 V is connected
to the vehicle. When the function 230 V has been activated the control
panel shall be turned off but 12 V shall still be connected. Some vehi-
cles may be equipped with a individual solution (winter connection*).
Temp sensor calib. If the boiler should be controlled by another tem-
perature than that where the sensor is placed, the temperature can be
adjusted by ± 5 °C. Also applies for outdoor sensor.
Display. Choose brightness on the panel: Low, Medium eller High.
Choose also if the status page should be Normal, Inverted or Dark.
If dark is chosen the panel goes out after 30 seconds and lights up
again if it is touched.
Settings menu, fig. 12
Sound. Start or stop button and warning/notification sounds.
Language. Change the language of the menus in the Control Panel,
available languages are: English, German and French.
Service. Shows values from the heating system, these are updated
continuously and describes the current status in the boiler. See sec-
tion 11 Service menu & reset.
System configuration, activate installed accessories and functions.
Here presents all accessories or functions that can be connected to
the Alde Heating System, activate those that are installed in the heat-
ing system to be able to use them.
Reset. Resets the boiler to fabric settings. The accessories/functions
that are chosen under System Configuration are not affected.
Settings
EisEx
Delayed Start
External Start
Temp sensor calib.
Display
figure 11. Settings
menu
Settings
Sound
Language
English
Service
System configuration
Reset
figure 12. Settings
menu
39
