Description of symbols for the main menu on the status page (fig. 6)
Zone icon, sofa. Shows current temperature and if circulation pump is
active in the zone ( ). Press the icon to change desired temperature.
Zone icon, bed. Shows current temperature and if circulation pump is
active in the zone ( ). Press the icon to change desired temperature.
Light*. Start, turn off or dim the lights on the AC (only with Truma AC).*
Energy. Shown which energy source that is being used, when gas
is used the flame turns red and when electricity is used the lightning
turns yellow. Press the icon to choose and prioritize energy source, set
up load monitor* and high altitude mode.
Hot water. Shown if hot water production is on, "boost" ( ) or turned off
( ). Press the respective control to start/turn off or increase hot water
production. The thermometer is completely filled when the hot water
has reached boost temperature. Read more in section 6.4 Hot water.
Outdoor temperature*. If an outdoor sensor is installed the current
outside temperature is shown.
6.3 Set desired temperature
The temperature can be set from +5 °C to 30 °C in steps of 0.5 °C. Set the tem-
perature by pressing each zone. The temperature that is shown (fig. 7) is that
which is currently set (fig. 7).
• Raise the temperature in the zone by pressing the plus button, to the right of
the temperature.
• Reduce the temperature in the zone by pressing the minus button, to the left
of the temperature.
You can leave the menu by using the back arrow in the top left corner, or by
pressing the button "menu" once, the heating system works towards the desired
temperature immediately.
WARNING Scalding injuries
When the hot water and the glycol mixture in the boiler is heated simultaneously, the hot water can
be very hot when a high level of heating is required.
6.4 Hot water
In the heating system there is a built-in domestic hot water tank with volume
on approx. 8,5 litres. The heating system can be used without fresh water in
the tank. There are three different settings for hot water: no hot water, normal
operation and prioritized hot water (fig. 8).
• No hot water or normal operation. Press the control to the right of the text
"Normal hot water" to switch between no or normal hot water production.
• Prioritized, "boost", hot water production. Press the control to the right of the
text "Boost 30 minutes". The boiler will now prioritize the production of hot
water during 30 minutes. When 30 minutes has passed the boiler returns to
previous settings. Prioritized hot water production is recommended at increased hot water need.
The hot water tank can also be used without the heating system being in operation. Set the desired
room temperature and activate hot water production. If the desired temperature already is reached
there is no need for heating, if hot water production is active the boiler will only produce hot water.
19:49
22.0
°C
22.0
°C
23
°C
Light Energy Hot water Outdoor
figure 6. Main menus
on Status page
Bedroom
On
22.0
°C
figure 7. Set zone
temperature
Hot water
Normal hot water
Boost 30 minutes
figure 8. Set hot
water production
