1.
Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
we hope your new tool brings you much enjoyment and
success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by the
product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified.
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device.
The operating instructions are intended to help the us-
er to become familiar with the device and take advan-
tage of its application possibilities in accordance with
the recommendations.
The operating instructions contain important informa-
tion on how to operate the device safely, professionally
and economically, how to avoid danger, costly repairs,
reduce downtimes and how to increase reliability and
service life of the machine.
In addition to the safety instructions in these operating
instructions and the safety instructions for the machine
mounted, you must also observe your country's regu-
lations applicable to the operation of this device and
the electric power tool mounted.
Keep the operating instructions package with the de-
vice at all times and store it in a plastic cover to protect
it from dirt and moisture. Read the instruction manual
each time before operating the device and carefully
follow its information.
The device can only be operated by persons who were
instructed concerning the operation of the machine
and who are informed about the associated dangers.
12 | GB
m Attention!
The electric power tool mounted on the universal ma-
chine stand may only be used by personnel who have
been trained in the use of the electric power tool and
who have been instructed with respect to the associ-
ated hazards.
The minimum age requirement must be complied with.
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such devices must also be observed.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions and
the safety information.
2. Device description
A.
Universal machine stand
B.
Support arm
C.
Crossbar
D.
Adjustable workpiece support
E.
Screw*
F.
Washer*
G.
Spring washer*
H.
Nut*
I.
Star-grip screw
J.
Star-grip screw
3. Scope of delivery (fig. 2)
• 1x Universal machine stand (A)
• 2x Support arm (B)
• 2x Crossbar (C)
• 2x Adjustable workpiece support (D)
• 4x Screw (E)*
• 4x Washer (F)*
• 4x Spring washer (G)*
• 4x Nut (H)*
• 4x Star-grip screw (I,J)
* The screws supplied to attach the machine to the
universal stand are suitable for a large number of ma-
chines. However, it is possible that these are not suita-
ble for your machine. In this case, you will have to buy
the appropriate screws yourself.
