11. Recalibra�on
The calibrator can be completely or par�ally recalibrated by the user.
Recalibra�on is carried out directly via the calibrator keypad (3rd menu level).
The internal sensor is compared with a standard at one or more temperature
points.
Calibra�on can only be carried out if the unit is set to °C.
The purpose of recalibra�on is to correct the error between the displayed temperature and the
value of a reference thermometer. To calibrate the internal sensor, a standard, i.e. a precision
thermometer, is required, which has a significantly higher measuring accuracy than the calibrator.
Calibra�on can be carried out at up to 10 temperatures. We recommend calibra�ng at least at the
following temperatures:
LR- Cal PYROS 140-1L
LR- Cal PYROS 375-DNV:
LR- Cal PYROS 650-DNV:
Follow this instruc�ons:.
1. Insert the probe of the standard thermometer in the most suitable hole of the insert.
Recommended inser�on depth: 40-50 mm.
2. Set the first calibra�on temperature point as set point and wait for complete stabiliza�on of
the device (see flashing icon in the display).
3. Enter the 3rd. menu level (see chapter 7.3 - 3rd. menu level). There, select the func�on „Pc".
4. Use the -keys to enter the value,
▲▼
key (Enter). Confirma�on is indicated by a beep. E
5. Repeat steps 2. to 5. for the other calibra�on temperature points.
At the end of the opera�on, wait for about 20 seconds to come back to the principal menu.
DRUCK & TEMPERATUR Leitenberger GmbH • Bahnhofstr. 33 • D-72138 Kirchentellinsfurt • GERMANY
Tel. +49 (0) 7121-90920-0 • Fax +49 (0) 7121-90920-99 •
LR- Cal
LR- Cal
and LR- Cal PYROS 140-2L
measured with
DT -Info@Leitenberger.de •
PYROS 140-1L + LR- Cal
PYROS 375-DNV + LR- Cal
: -10°C / 0°C / +50°C / +100°C
50°C / 120°C / 190°C / 260°C / 340°C
100°C / 200°C / 300°C / 400°C / 500°C / 600°C
the reference thermometer, and press
