4.1.4 Fuse replacement
For the LR- Cal PYROS 375-DNV
replaced:
230 VAC supply: 3.15 A fuse
115 VAC supply: 6.3 A fuse
A total of 4 fuses are included in the scope of delivery of these two models. One of them already
installed, the others in labeled bags.
For the models LR-
(except when replacing a defec�ve fuse with the same type).
1. Open the fuse compartment on the main switch (using a screwdriver to lever it out):
2. Remove the fuse to be replaced from
the holder:
4. Insert the fuse compartment back
into the opening of the main switch:
DRUCK & TEMPERATUR Leitenberger GmbH • Bahnhofstr. 33 • D-72138 Kirchentellinsfurt • GERMANY
Tel. +49 (0) 7121-90920-0 • Fax +49 (0) 7121-90920-99 •
LR-
LR-
and LR- Cal
(included in the scope of delivery, in the bag)
Cal PYROS 140-2L and
DT
Cal PYROS 140-1L + LR-
Cal PYROS 375-DNV + LR-
PYROS 650-DNV models, the fuse may need to be
(factory se�ng)
LR- Cal PYROS 140-1L
3. Insert the new fuse into
the holder:
5. Press the safety compartment in
un�l it engages fully:
-Info@Leitenberger.de • www.druck-temperatur.de
45
Cal PYROS 140-2L
Cal PYROS 650-DNV
NO fuse replacement is necessary
