7. Thermoregulator
7.1 Descrip�on of the panel func�ons
Symbol: Hea�ng
The symbol flashes
when the calibrator
is hea�ng
Display: Line 1
Shows value of internal
temperature or value
of func�on
selected with
F
key
Display: Line 2
Shows value of set
point or func�on
selected with key
F
Key: F
To scroll the func�on
of the menu.
2. level of the menu:
Press keys and
F
▲
together
Tel. +49 (0) 7121-90920-0 • Fax +49 (0) 7121-90920-99 •
PYROS 140-1L +
LR-
Cal
PYROS 375-DNV +
LR-
Cal
Symbol: Cooling
The symbol flashes
when the calibrator
Increases/reduces the
displayed set point value
or the value of the
func�on selected with
the key. Keep key pressed
F
to increase the speed.
DRUCK
&
TEMPERATUR
Leitenberger GmbH • Bahnhofstr. 33 • D-72138 Kirchentellinsfurt • GERMANY
PYROS 140-2L
PYROS 650-DNV
is cooling
Keys:
+
▲ ▼
DT
-Info@Leitenberger.de •
58
Symbol: Switch test
Indicates the status
of the thermostat
under test
Symbol: Stability
The symbol
flahes when the
calibrator is stable
Symbol: Ramp
(Switch test)
The symbol flashes
when the RUN
func�on is ac�ve
Key: E
Confirms the
set point or the
value of the
func�on selected
with the key.
F
