SICK PowerProx Micro WTT2SL Betriebsanleitung Seite 18

Distance value reproducibility
Distance value-accuracy
Light spot diameter/distance
Supply voltage U
B
Ripple
Current consumption
Output current I
max.
Switching frequency
Max. response time
Input
Enclosure rating
Protection class
Circuit protection
Ambient operating temperature
switching output
Setting
PIN2-Configuration
IO-Link
Max. response time SIO Direct
Max. response time SIO Logic
Max. response time IOL
Switching frequency SIO Direct
Switching frequency SIO Logic
Switching frequency IOL
Inverter
Smart Task label
Logic function
Timer function
1) Object with 6 % ... 90 % remission (based on standard white DIN 5033)
2) Equivalent to 1 σ.
3) With light / dark ratio 1:1
4) Signal transit time with resistive load
8021879.1A75 / 2020-12-11 | SICK
Subject to change without notice
TECHNICAL DATA
WTT2SL-2Xx92 WTT2SLC-2Xxx9xAxx
- 2 mm ... 5 mm
- ±20 mm
10.0 mm / 300 mm 10.0 mm / 300 mm
DC 10 ... 30 V DC 10 ... 30 V
≤ 5 V ≤ 5 V
ss
≤ 20 mA ≤ 20 mA
≤ 50 mA ≤ 50 mA
5 Hz 5 Hz
3)
typ. 90 ms , typ. 95 ms
4) 5)
- MFin = multifunction
input programmable
IP67 IP67
III III
A, B, D 6) A, B, D
-25 ... +50 °C 7) 25 ... +50 °C
PNP /NPN 8) PNP
Single teach-in button 9) Single teach-in button
IO-Link
- external teach, Teach-in
Input, Transmitter from
Input, detection output,
logic output
- IO-Link V1.1
COM2 (38,4 kBaud)
Cycle time 5 ms
Process data length 4
Byte
- typ. 90 ms
- typ. 90 ms
- typ. 95 ms
- 5 Hz
- 5 Hz
- 5 Hz
- YES
- Basis logic
- DIRECT
AND
OR
WINDOW
Hysteresis
- Deactivated
Switch-on delay
Switch-off delay
Switch-on and -off delay
Pulse (one shot)
10
2)
ss
3)
,
4) 5)
6)
7)
9) ,
10)
11)
12)
10)
11)
12)
17
