ENVIRONMENT
The device is delivered in a package to protect it against any possible
transport damage. The packaging is made from non-processed
material and can be recycled. Throw the materials to appropriate
colour containers for selective waste collection.
Protect the environment and do not throw used batteries
into household wastes. Return them to the point of sale
or a special recycling centre.
Used electrical equipment (including the computer and
power supply) are recyclable. Do not throw them out with
household waste as they may contain substances dangerous to the
health and environment. You can actively contribute to sustainable
use of natural resources and the protection of the natural
environment by handing the used device to a recycling centre for used
electrical devices.
ASSEMBLY
The device must be assembled carefully by an adult. In case of doubt,
ask a more experienced person for help.
• Prior to the assembly, make sure the set contains all
the listed elements and whether none of the parts was
damaged during transport. If any parts are missing or you have
any other reservations, contact the seller.
• Have a look at the drawings and explanations and follow the
assembly manual when assembling the device.
• Be careful during the assembly. There is a risk of injury when
using the tools and parts.
• Remember to keep your surroundings safe. Do not let tools
and parts lie around in chaos. Remember that plastic foil and
bags pose o suffocation risk to small children.
• Assembly parts necessary for a specific step in
the assembly manual are shown in pictures and included in
instructions. Use the elements indicated in the assembly
manual.
• Do not tighten parts completely during the first stages
of the assembly. Tighten connections after all parts are placed
and fitted properly.
• The manufacturer may have assembled some parts.
ASSEMBLY DIAGRAM (→ See page 2)
ATTENTION! Do not use parts other than those provided by the
manufacturer.
PARTS LIST
NO. DESCRIPTION
1 Main frame
2 L/R Treadmill columns left/right
3 Computer frame
4 Support
5 Front roller
6 Rear roller
7 Spring
8 Bushing Φ18*8
9 Gear plate t15*530*1155
10 Running belt t1.4*450*2570
11 Multi-ribbed belt
12 Upper computer cover
13 Lower computer cover
14 Foam handrail holder left
15 Foam handrail holder right
16 Upper motor cover
17 Lower motor cover
18 Inner cover of left treadmill column
19 Outer cover of left treadmill column
20 Inner cover of right treadmill column
21 Outer cover of right treadmill column
22 Treadmill column knob
23 Side rail
24 Rear frame cover
25 Transport wheel
26 Stabilizing feet
27 Shock absorber 1
28 Shock absorber 2
29 C-shaped cap
30 Computer cover knob
31 Rubber shock pads
32 Pulse sensor / Start/Stop quick start button
33 Pulse sensor / Quick change speed +/-
buttons
34 Control board
35 950mm safety key
36 Motor
37 Power on/off switch
38 AC adapter 1.8m
39 250V socket
40 Overload protection
41 Single wire 250V 270mm
42 Ground wire 250V 300mm
43 Screw M8*50
44 Screw 4.2*16
45 Screw 4.0*30
46 Screw 4.2*16
47 Screw M8*25
48 Screw 4.2*16
49 Screw 4.2*25
50 Screw M6*35
51 Screw M6*25
52 Screw M8*40
53 Screw M6*35
54 Screw M8*12
55 Washer Φ9* Φ16*t1.5
56 Washer D8
57 Washer Φ5.2* Φ10*t1
58 Screw 3.5*10
59 Nut M6 S10
60 Washer Φ10.5* Φ20*t2.00
61 Signal wire
62 1115mm adhesive strips
63 Wrench S6 / 80*80mm
ASSEMBLY MANUAL (→ See page 3)
CAUTION! Follow the steps below during the assembly and use tools
supplied with the product. Prepare sufficient space for the assembly
operation. It is advisable to assemble the product with another person
because of the weight of some elements.
QUANTITY FOLDING AND UNFOLDING (→ See page 6)
1
FOLDING THE DEVICE
1/1
NOTE! Before you start folding, check if all the bolts are tight and
1
disconnect the power supply cable.
1
NOTE! Be careful with your hands and fingers when folding so that
1
they do not get crushed.
1
Fold the computer and treadmill column using knobs. Stand the
2
2 folded device up vertically, as illustrated. Holding the running belt,
pull on the support and lower it to the ground.
1
1
UNFOLDING THE DEVICE
1
PLEASE NOTE! Ensure there are no third party or animals in the
1
immediate treadmill vicinity when its belt is lowered.
1
Holding the running belt, raise the support and then lower the device
1
so that the running belt is horizontal.
1
Unfold the treadmill columns and then the computer using knobs by
1
repeating steps 1 and 2.
1
1
ADJUSTMENTS
1
Levelling
1
Level the device by rotating the levelling feet in the rear and front
1
base.
2
2
COMPUTER MANUAL
1
4
START/STOP
2
The device starts five seconds after pressing the START/STOP button.
