4.4 - Autolearning of the travel stroke
The first time the control unit is powered up, or if a default with dif-
ferent motor type is performing, the display shown "
An autoleaning procedure must be carried out to acquire fundamen-
AUTOLEARNING OF THE TRAVEL STROKE AND MAIN PARAMETERS
The decelerations will be those set in the menu, with the same percentage during both opening and closing.
1. Release the gate or door, move it onto the central position and lock it in place again.
2. Hold down the (UP) and
en shows
3. If the first operation is NOT opening of the gate, press the
Then press (SBS) to restart the acquisition: the gate starts moving again, in the right direction. The motor
opens the gate at low speed to the opening limit switch. On reaching the opening limit switch, the gate restarts in
the closing direction at low speed until it reaches the closing limit switch, displaying
4. Perform a number of opening, closing and sudden stop commands to ensure that the system is solid with
no assembly defects.
All the main parameters are set with the default settings by the control unit. To customise the installation, proceed as described in point 4.5
below.
AUTOLEARNING OF THE TRAVEL STROKE WITH CUSTOMISED DECELERATIONS
Deceleration intervals can be customized by the user, according to the procedure below
CAUTION! check that mechanical end stops (compulsory) are present and secure. The motors must always
reach the mechanical end stop
1. Move the gate manually to mid-travel
2. CAUTION: enter the BASIC MENU to set the parameter
3. Press the buttons (UP) and
displayed, then (if necessary) press
If the first manoeuvre is NOT opening, press
Then press (SBS) to restart acquisition: the leaf resumes movement in the correct direction
4. The motor opens at low speed until it reaches the mechanical opening end stop. After a couple of seconds it
will restart in closure (the display shows
5. On reaching the point where motor is in closing deceleration is required, press
movement continues at low speed (the display shows
6. On reaching the mechanical end stop of motor it starts to opening
7. On reaching the point where motor is in opening deceleration is required, press
movement continues at low speed (the display shows
8. When the motor reaches the open position, it will stops for a couple of seconds and then it restarts closing at
normal speed. When the gate is closed the learning procedure it is finish
4.5 - Learning a transmitter
A transmitter can be memorized via the specific programming menu or by remote memorisation, using a previously memorised transmitter.
4.5.1 MEMORISING A REMOTE CONTROL
If you are in programming mode exit pressing the
(DOWN-RADIO) button for more than 2 seconds. Until the display shows the word
release the button
1. Press and release the
be selected: once for function STEP BY STEP (
times for function ONLY OPEN (
times for output
ON/OFF)
2. The KEY LED will flash a number of times equal to the number of the function selected, with 1 second pauses
between flashes
3. Within 7 seconds press the button of the remote control to be memorized
4. If the memorization has been successful, the KEY LED will give one long flash
5. To memorize another remote control on the same function, repeat point 3
N.B If no commands are given for 7 seconds, the receiver automatically quits the programming mode
