9. REMOTE CONTROL UNITS
Programming the remote controls
Press the "P2/RADIO" push-button until the red led lights up, indicating programming is under process.
jumper JP1).
plete, the LED will be lit steadily. A new code may then be stored.
exit this mode after 10 seconds of non-use.
Deleting the transmitter codes
Hold the "P2/RADIO" button pressed approx. for 6 seconds until the red LED starts slowly flashing.
Press again the "P2/RADIO" button until the red led flashes more rapidly to indicate the elimination.
WEATEM 4 transmitter
General information
The transmitter supplied sends a secure rolling code over a 433.92 MHz frequency.
It is powered by a supplied battery CR2032 (3 VDC), and must be programmed on the board.
Changing the battery:
Open the battery compartment cover on the lower part of the transmitter (Fig. 1).
Replace the battery following the polarity marked (Fig. 2).
Fig. 1
A
B
C
D
A, B, C or D on the remote control (depending on the position of
P2/RADIO button again to exit. The LED shuts off. The board will automatically
Fig. 2
CR2032
+
If changing JP1 position, a reprogramming is not necessary.
WEAT V2 N - V1
Chronological order of buttons:
Channel A: FULL control (if JP1 removed from board)
Channel B: PARTIAL control, one leaf (if JP1 removed from
board)
Channel C: FULL control (if JP1 on board)
Channel D: PARTIAL control, one leaf (if JP1 on board)
20GB
-
