Concrete structures must be professionally made; if required, contact a professional.
A gate or door in poor condition or badly installed cannot be automated. If you are unsure, contact a
professional.
d – RECOMMENDATONS FOR INSTALLING YOUR AUTOMATED SYSTEM
Badly handled or damaged parts must be returned to us for checking or repair.
- Check that the clearance area for operators (worm screws, arms or sliders) is clear and obstacle-free (cut bushes
and hedges if necessary).
- Do not make any changes to parts of this automated system that are not authorised in this manual. These
changes could make its use very dangerous. The manufacturer will not be held responsible for any damage resul-
ting from these changes and will cancel the guarantee.
- All installation and maintenance must be done with an electrical supply and optional disconnected battery (and
highlight your presence in a passageway with a sign for example).
- Always use appropriate tools which are in good condition.
- Fixed and moveable parts must be solidly and professionally attached and stable for the duration.
- Do not expose any parts of this kit to rain or strong heat during installation. Using the automated system in
these conditions can be very dangerous.
- Do not submerge parts of the automated system in water or any liquid substances. Using the automated
system in these conditions can be very dangerous.
- If liquid gets into the automated system, disconnect it immediately by following the safety procedures for the
electrical network. Using the automated system in these conditions can be very dangerous.
- The installer must check that the temperature during use is complied with.
- The installer must ensure that access to the manual release button is always available.
- The installer must ensure that moveable or fixed parts are protected from shock (protect them if required).
Moveable parts must be clear and obstacle-free.
- The installer must check that there are no crushing or cutting areas. All safety procedures must be followed to
eliminate these problems.
- The alignment of photo-electric cells is very accurate; ensure that their connections are stable and on a flat
surface.
- The flashing light must be visible from the road and is obligatory.
e – ELECTRICAL CONNECTION AND INSTALLATION
The EN 12445 standard outlines the test methods to check the gate's automated systems.
- The installation, electrical connections, and adjustments must be professionally done by a qualified and specia-
lised individual according to the standards in force in the country where this product is installed (NF C 15-
100 for France).
- Use 3 x 1.5 mm2 cable up to 30 metres long and 3 x 2.5 mm2 beyond that. Protect the unit with a differen-
tial 30 mA circuit-breaker and with a bipolar 10A circuit-breaker. Check your electrical installation is properly
earthed. Have an all-pole cut-out device in the network and an emergency shutdown button close to the
automated system is recommended.
- We recommend you supplement your electrical installation with a surge suppressor.
- The ligthing system in the clearance area around the gate must be grounded or double insulated
- Prior to installation, ensure that covers and protections are properly screwed or well fitted together.
- Only modify the original parameters if required and with care (speed, sensitivity, etc.).
- For safety, at installation, ensure that an individual is close to the gate.
- The electronic card is a high technology sensitive product and does not tolerate mishandling, in particular
around the radio card and its adjustment potentiometers.
- All safety parts must be checked prior to validating the installation.
4GB
WEAT V2 N - V1
