5. DIMENSIONS
6. T YPICAL CONNECTION
Battery kit
(option)
230 VAC mains
Fuse (5x20)
250V 1AT
power supply
To transfo
live
RX
PHOTOCELLS
After protecting the power supply with a
neutral
10 A two-pole circuit breaker and a 30 mA
GFCI, is to be connected to the terminal
board inside the cabinet.
230 V mains
power supply
10GB
WEAT V2 N - V1
Drive slide
Flashing beacon
TX
