Connections and connector pin assignments

Connections for
robot controls to
Robacta FB
8I_8O (Robacta
CTC)
Connections to Robacta FB 8I_8O
Connections for
robot controls
on the outside of
Robacta TX, TX
10i, TX/i TWIN
38
(1)
(2)
(1) Supply connection +24 V AIDA
for supplying the fieldbus coup-
ler and the I/O terminals
(2) Standard I/O 1 connecting
(3)
plug
for connecting to Robacta CTC
(3) Perforated plate with rubber
bushings
(1) Perforated plate with rubber
bushings
(2) Supply connection +24 V AIDA
(1)
for supplying the fieldbus coup-
ler and the I/O terminals
(2)
