Error
code
4 pulses
5 pulses
9 pulses
13 pulses
14 pulses
15 pulses
16 pulses
17 pulses
62
Reason
for
error Cause
0 pulses Terminal bus data error
n pulses Break behind terminals
(0:coupler)
n pulses Terminal bus error during
register communication
with terminals
0 pulses Checksum error in pro-
gram flash.
n pulses The n bus terminal does
not match the configura-
tion that existed when
the boot project was
created
0 pulses Runtime communication
bus command error
n pulses n bus terminal has incor-
rect format
n pulses Number of bus terminals
no longer matches
n pulses Length of the communi-
cation bus data (bit
length) is no longer cor-
rect. n = bit length after
booting
n pulses Number of bus terminals
is no longer correct. n =
number of terminals af-
ter booting
Remedy
One of the terminals is
faulty Remove half of the
connected terminals and
check whether or not an
error still occurs with the
remaining terminals.
Continue this process
until the faulty terminal
is found
Check whether or not the
n+1 terminal is inserted
correctly, replace if ne-
cessary
Check whether the
KL9010 end terminal is
inserted
Replace terminals
Reset to factory settings
using the KS 2000
Reset to factory settings
using the KS 2000, the
boot project is deleted
A bus terminal is faulty.
Remove half of the bus
terminals and test the re-
maining bus terminals for
faults. Repeat the pro-
cess until you locate the
faulty bus terminal.
Restart the coupler, if the
error reoccurs replace
the bus terminal
Restart coupler. If the er-
ror reoccurs, reset to fac-
tory settings using the
KS 2000
Restart coupler. If the er-
ror reoccurs, reset to fac-
tory settings using the
KS 2000
Restart coupler. If the er-
ror reoccurs, reset to fac-
tory settings using the
KS 2000
