Connecting and configuring the field bus coupler

Safety

Danger from electrical current.
This can result in serious personal injury and damage to property.
▶
▶
▶
Field bus coup-
ler controls and
connections
Connecting and
configuring the
field bus coupler
Danger from electrical current.
This can result in serious damage to property.
▶
50
WARNING!
Before starting work, switch off all devices and components involved and dis-
connect them from the grid.
Secure all devices and components involved so they cannot be switched back
on.
After opening the device, use a suitable measuring instrument to check that
electrically charged components (such as capacitors) have been discharged.
(1)
(2)
CAUTION!
Before starting work, ensure that the cables for the external power supply to
the interface are and remain de-energised until all work is complete.
(1) Profibus connecting plug
(2) Address selector
(3) Connections for external power
supply
(3)
IMPORTANT! External power supply
must not come from the power source.
Use the robot or control for the exter-
nal power supply.
