NEXUS 5-speed Internal Hub
SG-C7000-5D
13
27 29
2
3
ITEM NO.
SHIMANO CODE NO.
1
Y3FJ98010
2
Y3FF49000
3
Y3FF98020
4
Y38X98050
5
Y3FJ98020
6
Y3FF98040
7
Y3FF98050
8
Y3FJ98030
9
Y31L04000
10
Y31L98030
11
Y34R09000
12
Y35Z11000
13
Y35Z19000
14
Y31L98040
15
Y37710000
16
Y32T08100
17
Y36U98030
18
Y37G98080
19
Y3FF47000
20
Y70811000
21
Y13098022
22
Y70821000
23
Y04130100
14
16 17
15
1
4
5
DESCRIPTION
Internal Assembly (Axle Length 187 mm)
Stop Ring Diameter (12 mm / 1.3 mm)
Carrier Unit
Ball Retainer O (3/16" x 26)
Hub Axle Unit (Axle Length 187 mm)
Driver Unit
Ball Retainer A (7/32" x 13)
Right Hand Cone w/Seal
Drive Plate
Lock Washer
Joint Nut Stop Washer
Right Hand Serated Lock Nut (5.4 mm)
Left Hand Serated Lock Nut (10.7 mm)
Left Hand Cone w/Dust Cap & Seal Ring
Seal Ring
Left Hand Inner Dust Cap
Ball Retainer (7/32" x 9)
Right Hand Dust Cap A w/Seal
Right Hand Dust Cap C
TL-AF30 Left Hand Inner Dust Cap Installation Tool
TL-S702 Right Hand Cone Installation Tool
TL-C7001 Right Hand Cone Removal Tool
Internal Hub Grease (Net. 100g)
1
18
Internal Assembly
6
7
8
9
10 11 12
ITEM NO.
24
25
26
27
28
29
30
31
32
33
34
35
32
30
CJ-C7000-5
19
31
33
34
TL-AF30
TL-S702
TL-C7001
20
21
22
Internal Hub Grease
23
SHIMANO CODE NO.
DESCRIPTION
Y00298010
WB maintenance oil set
Y00201000
WB maintenance oil (1L)
Y00201100
Bottle
Y31414010
Cap Nut (3/8")
Y33Z20500
Non-turn Washer 5R (Yellow)
Y33M39600
Non-turn Washer 6R (Silver)
Y33M39700
Non-turn Washer 7R (Black)
Y34R85010
Non-turn Washer 8R (Dark Blue)
Y33M39510
Non-turn Washer 5L (Brown)
Y33M39610
Non-turn Washer 6L (White)
Y33M39710
Non-turn Washer 7L (Gray)
Y34R85000
Non-turn Washer 8L (Dark Green)
Y0FM24000
Sprocket Wheel 24T (CS-C7000)
Y0FM01000
Sprocket Wheel 27T (CS-C7000)
Y0FM30000
Sprocket Wheel 30T (CS-C7000)
Y7ZP04000
Snap Ring
Y7ZP98010
CJ-C7000-5 Cassette Joint Unit
Y7ZP98030
CJ-C7000-5 Cassette Joint Unit for Belt drive system
Y7ZP05000
Driver Cap
Y7ZP98020
CJ-C7000-5 Cassette Joint
Y7ZP98040
CJ-C7000-5 Cassette Joint for Belt drive system
Y33Z98020
Cassette Joint Fixing Ring
