Anhang
9.5
Tabelle 5
Die Tabelle 5 besteht aus 5 Segmenten. Sie enthält den Status der LED.
Seg-
ment
Byte Inhalt
0
RUN
1
DIAG
2
FAULT
3
IFAULT
4
OFAULT
5
FAULT 1: Erweiterungsmodul
0
rechts
6
FAULT 2: Erweiterungsmodul
rechts
7
FAULT 3: Erweiterungsmodul
rechts
8
FAULT 4: Erweiterungsmodul
rechts
9
FAULT 5: Erweiterungsmodul
rechts
10
FAULT 6: Erweiterungsmodul
rechts
11
FAULT 7: Erweiterungsmodul
rechts
12
FAULT 8: Erweiterungsmodul
rechts
Bedienungsanleitung PNOZmulti Kommunikationsschnittstellen
1001154-DE-13
Beispiel/Erläuterung
Abhängig vom Zustand der LED steht folgender Hex-
Code in Byte 0 ... 12:
00 hex: LED aus
FF hex: LED an
30 hex: LED blinkt
