General
General require-
NOTE!
ments
The automatic-welder interface ROB 3000 is only supported from software version
2.65.001 upwards (power source). Older software versions will need to be updated.
Machine concept The ROB 3000 is designed to be installed in a control cubicle, although it can also be
mounted in practically any desired position.
Advantages:
-
-
-
-
-
-
-
Where desired, the automatic-welder interface ROB 3000 can be combined with a field-
bus coupler (see the section headed "Parallel operation of ROB 3000 and field bus").
This makes it possible to operate a power source from two control units. Parallel opera-
tion of the ROB 3000 with a field-bus coupler is described in detail in the section hea-
ded "Parallel operation of ROB 3000 and field bus".
For parallel operation of the ROB 3000 with a field-bus coupler, a LocalNet passive distri-
butor (4,100,261) and/or active distributor (4,100,298) is needed.
NOTE!
The LocalNet passive distributor cannot be used together with a TIG JobMaster
welding torch.
Features of the ROB 3000 (4,100,254)
ROB 3000 -
-
-
NOTE!
For safety reasons, the Qick-Stop signal is intended to quickly stop the welding
process and provides machine safety only. In case also personal safety measures
are required, use an appropriate Emergency Stop Switch.
-
-
Linked up to power source via standardised LocalNet interface
No need for any modifications to the power source
Power source can easily be changed
Simple plug-in connections
Limited amount of wiring and cabling needed
High degree of interference immunity during data transmission
Can be mounted using top-hat rail holder
Digital input "Robot ready" / "Quick-Stop"
Digital inputs "Job BIT 0" and "Job BIT 1" (Job selection via the automatic-welder
control system)
Digital input "Arc ON"
Digital output "Power source READY"
Digital output "Current flow signal"
