Digital input signals (signals from the control sys-
tem)
General remarks
Danger of an electric shock.
This can result in serious injury and damage to property.
▶
The digital inputs and outputs are galvanically separated:
-
-
-
For each of the digital input signals, there is a GND and an input (HI) with external 24 V
activation, or alternatively, a potential-free input (LO).
To initialise a digital input signal
-
-
-
Signal level for the HIGH-active inputs:
-
-
Reference potential: GND for the relevant input signal
Arc ON Terminal 1/1..... 24 V to HI (signal initialised)
Terminal 1/2..... alternatively: GND to LO (signal initialised)
Terminal 1/9..... GND
The signal "Arc ON" starts the welding operation. The welding operation remains active
as long as the "Arc ON" signal is present.
Exception:
-
-
A welding sequence corresponding to the selected operating mode (2-step mode, 4-step
mode, aluminium welding start-up, ...) is now started up.
Exception:
-
-
IMPORTANT! If the "Arc ON" signal is not initialised, or not wired-up, the welding opera-
tion can be started by pressing the torch trigger.
30
WARNING!
The automatic-welder interface ROB 3000 must not be used for controlling any com-
ponents that are directly connected to the mains.
from one another
from the LocalNet and the welding potential
for a maximum voltage difference of 100 V
connect the GND for the relevant input signal to the respective GND of the automa-
tic-welder control system
IMPORTANT! If the automatic-welder control system only has one shared GND for
its digital output signals, then the GND's on the automatic-welder interface must be
linked to one another.
switch the 24 V from the automatic-welder control system to the input (HI) or
connect the potential-free input (LO) with the GND for the relevant input signal via a
potential-free switch (relay)
LOW...... 0 - 2,5 V
HIGH ..... 18 - 30 V
The digital input signal "Robot ready" is absent
The digital output signal "Power source READY" is absent
The digital input signal "Robot ready" is absent
The digital output signal "Power source READY" is absent
