4.3 Forming Mode
The LE-D 10 charging units are equipped with a forming mode for the rechargeable batteries inside the microphone units. The
batteries are formed and charged at the factory. If you have not used the microphone units for several months, you should form the
batteries before you set up the microphone units. Do this as described in the following:
• First of all remove all microphone units from the charging compartments.
• After switching on the charger press the buttons in the bottom of the two furthest charging compartments (next to the contact
pins in the round gap).
• Pressing one of these buttons will activate the forming mode for 5 charging compartments. The LEDs will flash rapidly.
• Then put the microphone units into the charging compartments. The LEDs will flash short and long.
• When the green LEDs are permanently on, then the battery is full.
Caution:
Only form empty batteries, but never full batteries!
Do not switch off the charging unit during the forming mode, as this will interrupt the forming mode.
The forming mode will be terminated automatically when the microphone units are fully charged or when the charger is switched
off.
5. Battery Charging with external CA 2456 Charger
The MCW-D microphone units can be also charged with the CA 2456 external charger which is connected to the multi-function
socket (1).
Important:
The automatic switching off of the microphone units when they are charged is not possible with the CA 2456. Therefore, the
microphone units must be switched off manually (or via the MCW-D 100 control unit) before charging.
Note:
It is normal that the rechargeable batteries are heated up during the charging process.
The charging time is around 3 hours when the battery is completely empty.
6.

Components

MCW-D 1011 Delegate microphone unit without loudspeaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 459.135
MCW-D 1013 Chairman microphone unit without loudspeaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 459.143
MCW-D 1021 Delegate microphone unit with loudspeaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 459.119
MCW-D 1023 Chairman microphone unit with loudspeaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 459.127
MCW-D 1041 Delegate microphone unit with loudspeaker and display . . . . . . . . . . . . . . . . . . . . . . . . Order # 465.445
MCW-D 1043 Chairman microphone unit with loudspeaker and display. . . . . . . . . . . . . . . . . . . . . . . . Order # 465.453
MCW-D 1641 Delegate system unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 469.513
MCW-D 1043 Chairman system unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 469.521
MCW-D 100 Control unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 495.151
MCW-D 1003 Programming device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 465.402
MCW-D 10 Charging and transport case for 10 microphone units . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 462.691
LA 10 Empty compartment for MCW-D 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 458.708
LB 10 Bottom for MCW-D 10 with trolley wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 458.716
LD 10 Cover for MCW 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 458.686
LE-D 10 Charging unit for MCW-D 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 462.683
LM-10 Compartment for 19"-mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 551.686
34
