3.3 Auto-Off-Function

The delegate microphone units have a power saving auto-off function, i.e. if no-one speaks into the microphone for more than
20 seconds, the microphone unit switches off automatically. The auto-off-function has been deactivated at the factory. The response
threshold and the time after which the microphone switches off can be adjusted with a programming device or PC using the Editor
software. The illuminated ring of the gooseneck microphone will flash 5 seconds before the microphone unit is switched off.
3.4 Addressing the Microphone Units / Serial Number
At the factory each microphone unit is programmed with a different identity number so that the MCW-D 100 control unit can
control them individually. This number is printed on the bottom.
When you subsequently order more microphone units later, please inform the supplier of your current identity numbers to avoid
duplication.
3.5 Safety Code
Using the MCW-D Editor software or the MCW-D 1003 programming device a safety code can be entered for the MCW-D micro-
phone units and the MCW-D 100 control unit within one system. This will increase the safety against unauthorised listening. For a
detailed description please refer to the appropriate manuals.
3.6 Documentation Output
For recording the conference you can connect a recorder to the documentation output (4). The volume can be adjusted with the
programming device or a PC using the Editor software. Instead of a recorder it is also possible to connect a headphone (e.g. DT 301) to
the documentation output (4). We recommend a min. impedance of 200 Ω.
3.7 Safety Note for the Charging Contacts of the Microphone Units
The charging contacts of the microphone units can cause damages, injuries or fire damages if they come into contact with
conductive materials such as jewelry, keys or chains. This can lead to a closed circuit and heat up the material. To avoid an unwanted
closed circuit treat the charging contacts with care, especially when the microphone units are carried in a bag or other containers
together with metallic objects.
Important
• Remove the transportation protection (a piece of cardboard) from the charging compartment of each microphone unit before use.
When the unit is transported again, replace the transportation protection.
3.8 Maintenance of the MCW-D Microphone Units
For cleaning the MCW-D microphone units when they are slightly dirty (finger prints, dust, jam or juice) use a soft, damp cloth,
sponge or brush and a liquid cleaning agent. Before cleaning the surface it must be moistened thoroughly. Afterwards it must be
cleaned with clear water. Make sure not to allow any water to enter the unit. For dirt caused by mineral oils and fats, animal and
vegetable fats use spirit, isopropyl alcohol or benzine.
For dirt caused by ballpoint pens, typewriter ribbons or carbon paper use isopropyl alcohol or spirit.
Clean the supplied pop shield with clear water. Make sure that it is completely dry before you put it on the microphone again.
