EP 6PTX HR
Fig. 13 - English
Setting of tightening torque – RE-versions
–
+
Torque level
Accuracy
Min. 3 pulses
Max. 3 seconds
–
+
+ +
– –
3 mm
Torque level
Accuracy
Min. 3 pulses
Max. 3 seconds
Start
Set the
tightening torque
Check the
tightening
on your
actual joint
Trim valve
Not OK
(inside)
Reduce / adjust
the free speed
Check the
tightening
on your
actual joint
Not OK
Atlas Copco Tools - No. 9836 1948 00
OK
Fully opened = max speed
= 75 % of max speed
ca 4 turns
OK
Technical Instructions
Put the machine
in operation
Put the machine
in operation
