Spare parts list
Fig. 3 Pulse unit HR-10
OFF 2 Nm
2.5 mm
34
37 36 35
33 32
29
= Included in O-ring Kit
= Included in Service Kit
Ref. No. Ordering No.
1 (2-37) 4250 2427 80
2 4250 2427 00
3 4250 1814 00
4 4250 1800 00
5 0196 1552 66
6 4250 1759 00
7 4250 1760 00
8 (9-10) 4250 1813 80
9 –
10 4250 1853 00
11 –
12 0517 0102 02
13 4250 1869 00
14 4250 1816 01
15 4250 1815 00
30
OFF 50 Nm
No. : 4080 0819 80
25
28 27 26
31 30
23 24 22
NB Qty Description
c 1 Pulse unit
(3/8" square drive)
1 Housing
1 Stop pin
1 Spring
1 Stop screw (S6SS5x5)
1 Pin
1 Washer
1 Inertia body
1 Inertia body
1 Stop screw
a,b 1 Lock ring
1 Pin (NRA2x9,8)
1 Spring guide
1 Spring (yellow)
1 Adjustment screw
Atlas Copco Tools - No. 9836 1948 00
OFF
Secure with Loctite 243
(12)
Silastic 732 RTV
(2)
OFF
Secure with Loctite 243
21 20 19
1
Ref. No. Ordering No.
16 4250 1863 00
17 4250 2449 00
18 4250 2450 00
19
20 4250 1808 00
21 0517 1106 00
22 4250 1818 00
23 4250 1809 01
24 4250 1810 01
25 (26-28) 4250 1807 90
26
27 4250 1948 00
28 4250 1949 00
29 (30-33) 4250 1812 91
30
31
32
33 0211 1102 00
34 (35-37) 4210 2873 90
35 4250 1686 00
36
37 0335 1115 00
Accessory Included
38 4080 0823 00
a Included in Service Kit – 4081 0252 90
b Included in O-ring Kit – 4250 2058 92
c Oil included
d Assemble according to fig. 1
6 Nm
OFF
2.5 mm
No.: 4080 1160 80
18 17
5
2
3
4
12
16
13
3 Nm
14
15
– +
Setting of tightening torque
38
NB Qty Description
1 Screw
1 Cover
2 Diaphragm
– a,b 1 O-ring (27,1x1,6 Viton)
1 Cam shaft
1 Ball (4 mm)
1 Washer
2 Piston
2 Roller
1 Anvil, compl.
– 1 Anvil
1 Retainer pin
1 Spring
1 Screw ring, compl.
– a,b 1 O-ring
– 1 Screw ring
– a,b 2 O-ring (2,6x1 Viton)
2 Screw (MC6S3x4)
d 1 Bearing kit
1 Washer
– 1 Ring
1 Circlip (SgA 13)
1 Adjustment key
EP 6PTX HR
1 Nm
8
9 10
11
6 7
