EP 6PTX HR
Fig. 4 Motor
102 101
104
OFF
20 Nm
= Included in Service Kit
Ref. No.
Ordering No.
80 (82-99)
4250 1793 82
82
–
85
4250 1794 02
86
0101 1150 00
89
4250 1793 02
91
4250 1802 90
92
4250 1796 00
93
–
95
0337 2515 00
99
98
97
95
The screw ring shall be tightened
before ref. 55 Fig. 5 (Motor Casing)
is tightened.
NB Qty
Description
1
Motor, compl.
a
1
Ball bearing (X8ZZ)
1
End plate
1
Pin (CP 2h6x8)
1
Cylinder
1
Plug kit (7)
1
Rotor
a
7
Vane
1
Key (2x2x12)
Atlas Copco Tools - No. 9836 1948 00
80
93
92
91
EP 6PTX= Ø3 mm
0.9 ± 0.1 mm
(90)
(98)
(97)
Ref. No.
Ordering No.
97
4250 1795 02
98
0517 0102 02
99
101
4250 1803 01
102
4250 1804 00
103
4250 2231 00
104
a Included in service kit 4081 0252 90
Spare parts list
89
86
85
82
103
NB Qty
Description
1
End plate
1
Pin (NRA2x9,8)
–
a
1
Ball bearing (6000-2Z)
1
Spacing collar
1
Screw ring
1
Washer
–
a
1
O-ring (35.2x1)
31
