CPU not operating
after pressing Start
Telescopic tubes
constantly hit the
same side of the
container, and do not
move further
Operator´s panel
shows "Telescope
safety switch on"
Operator´s panel
shows "Telescope
minimum / maximum
position exceeded"
Operator´s panel
shows "Confirm wire
not broken"
Operator´s panel
shows "Acknowledge
motor fault"
18
Components blocked in telescopic
pipe or suction hose (or possibly
bottom valve / piping on CVL).
Level sensor in CVL or on con-
tainer under CVL (or other sensor
in the system) sends incorrect sig-
nal to CVL control.
Start / stop switch on CVL control
is in position Stop
The CPU control depends on a
switch at the bottom of the tel-
escopic pipe, to detect the sides
of the container. Sometimes this
switch will not detect the side, and
then the telescopic pipe continues
its movement. This causes the tel-
escopic pipe to repeatedly hit the
side of the container. To mitigate
this, the CPU has a built-in timer
that detects whether the telescop-
ic pipe is stuck in the program,
and causes the telescopic pipe to
move in another direction.
Pickup end of the telescopic pipe
briefly rests on the components
in the container or on the upper
edge of the container.
The program will not stop
Pickup end of the telescope pipe
has reached the specified outer
limit
The telescopic pipe's wire broken
or dropped by the wire wheels
(the program will stop)
Telescopic pipe jammed onto the
components (the program will
stop)
Overheating or defect on the mo-
tors
Switch off the CPU system with the emergency stop
on the side of the CPU column (possibly to prevent
CPU motors from overheating). Remove blocked
components, see section "Operation". Reset the
emergency stop and select "Confirm safety" on the
operator panel.
If the telescopic pipes cannot be raised manually, it
may be a sign of a blocked pipe.
Check if sensors send the correct signal to the CVL
control, and adjust / replace the sensor if necessary.
Set switch to Start position
If the telescopic pipe repeatedly hits the side for more
than 10 seconds, and it does not continue in another
direction, press the Stop button, after which the tel-
escopic pipe returns to its original position. Then Start
can be selected again.
If the CPU does not respond by pressing the Stop
button, the system is interrupted by the emergency
stop on the side of the CPU coloumn. With the emer-
gency stop activated, it is checked whether there are
mechanical faults, which can be rectified if neces-
sary. The emergency stop is then reset, and "Confirm
safety" is selected on the operator panel
The error message disappears, after pressing "Ac-
knowledge" on the operator´s panel
The error is deleted on the operator´s panel. If the
error occurs again, call service
Remove the side covers on the suction head and
check if the wires are properly seated. If not, reattach
wire or call for service
The error message disappears, after pressing "Ac-
knowledge" on the operator´s panel
Allow motors to cool down. If necessary, replace mo-
tors. The error message disappears, after pressing
"Acknowledge" on the operator´s panel
