BUOYANCY CHAMBER - INFLATING THE BUOYANCY CHAMBER
II-4 INFLATING THE BUOYANCY CHAMBER
INFLATOR
a. tube end
b. adaptor
c. tube base
d. inflation port
NOTE: A high capacity electric (12 V) inflator is available as an option (contact your dealer).
"EASY-PUSH" VALVES
To change position
Push
613770 A
d
Inflation position
The membrane is closed, the
plunger is up
Page 29 / 65
a
b
c
Deflation position
The membrane is open, the
plunger is down
Edition 2
