Zodiac OPEN 3.1 Eignerhandbuch Seite 114

11
12
16
9
17
Ref.
1 Battery connection
2 Circuit breaker connection
3 Bus bar ground connection
4 Navigation light switch connection
5 White light connection
6 Petrol gauge dial connection
7 Red green light connection
8 Petrol gauge transmitter connection
9 Positive bus bar connection
12 Volt power socket connection (console)
10
11 USB plug connection
12 Radio set connection (optional)
13 Bilge pump switch connection (optional)
14 Bilge pump connection (optional)
15 3A fuse USB socket
16 5A fuse 12 volt socket
17 3A fuse navigation lights
18 5A fuse bilge pump
613770 A
INSTALLATION AND CIRCUIT: ELECTRICITY
13
10
15
14
Purple 4 AWG18
Purple 3 AWG18
Red 6 & 7 AWG18
Purple 3 AWG18
4
DESCRIPTION
Page 46 / 65
6
3
Edition 2
8
7
