Zodiac OPEN 3.1 Eignerhandbuch Seite 77

I-4 TECHNICAL CHARACTERISTICS OF THE OPEN 4.8
(Directive 2013/53/EU)
(ISO)
ISO 14946
ISO 14945
Number of compartments
613770 A
DESCRIPTION - Technical characteristics
Dimensions
Dimension tolerance +/- 3%
m 4.7
ft 15' 5"
m 2.92
ft 9' 7"
m 2.09
ft 6' 10"
m 1.1
ft 3' 7"
HA (mm) 1085
T (mm) 485
° 17.5
mm 537
Design category
Capacity
Weight tolerance +/ – 5%
I
6
Kg 590
lb. 1301
Kg 760
lb. 1676
Kg 310
lb. 683
5
Page 9 / 65
Buoyancy chamber diameter
Without the buoyancy
a
chamber
b
c
ft
Max. air draught
Max. draught
Transom angle
Transom height
I
Maximum load i.a.w. ISO 14946 (1+2+3+4) data
figuring on the ICNN certificate.
Maximum load i.a.w. ISO 14945 (1+2+3+5) data
figuring on the manufacturer plate.
Weight of people
Personal property
List of all options proposed
Content of consumable liquid tanks (fuel,
drinking water, etc.)
Weight of the engine or engines
The weights indicated do not include any
accessories
m 0.5
ft 1' 8"
m 3.83
ft 12' 7"
m 1.38
ft 4' 6''
m 1.38
4' 6''
Edition 2
