V-1-2- Portable tank (optional)

Nominal capacity
= 24L / 6 GAL
1
Nominal capacity
= 46L / 12 GAL
1
Ref.
1 Portable tank *
2 Suction tube
3 Tank filler inlet
4
Gauge transmitter
Note: the tank option provides quick connectors and holding straps in order to be able to extract the
tank without using tools. Each time before you sail, check that it is correctly held in place and that
the connectors are fully connected.
*It may not be possible to use the full nominal capacity of the tank depending on the trim and the
load. A 20% reserve is recommended.
