INSTALLATION AND CIRCUIT

V-1 FUEL CIRCUIT
WARNING!!!
DO NOT USE TYPE E10, E85, ETC. BIOFUELS.

V-1-1- Component locations:

Ref.
1 Tank and filter access
2 Fuel tank (optional)
3 Filling hole with cap
4 Water/fuel separator filter (not supplied)
613770 A
INSTALLATION AND CIRCUIT: FUEL
