I-6-1-1- Installation
•
Present each item of equipment on the deck, lining it up with the holes, without screwing in,
•
Check that the items of equipment are parallel with each other and the transom,
•
Use the holes in the console and the bolster to mark the positions of the holes on the deck,
•
Remove the equipment and drill with a Ø4.2mm bit,
•
Clean and place SIKAFLEX 221 around each hole and between each hole in order to create a
peripheral seal.
•
Present the equipment on the deck and screw in.
•
Clean off the excess SIKAFLEX
•
Create a peripheral finishing seal on the internal section of the console to ensure better
waterproofing.
613770 A
DESCRIPTION – INVENTORY and location
Page 17 / 65
Peripheral finishing
seal
