Ethernet Interface
combiSENSOR
All manuals and user guides at all-guides.com
6.4.4

Averaging Type (AVT)

Mode of measurement averaging
AVT
Command $AVTn<CR>
Response $AVTnOK<CRLF>
Index
n = 0: No averaging (Default setting)
n = 1: Moving average
? = Request averaging type
Request averaging type
Command
$AVT?<CR>
Response $AVT?nOK<CRLF>
6.4.5

Averaging Number (AVN)

Number of measuring values used to calculate the average (adjustable from 2 ... 4).
AVN
Command $AVNn<CR>
Response $AVNnOK<CRLF>
Index n = 2 ... 4
? = Request averaging number
Request averaging number
Command $AVN?<CR>
Response $AVN?nOK<CRLF>
6.4.6

Channel Status (CHS)

Returns the available channels: 0 = channel not available, 1 = channel available
2 = mathematic function on channel active
CHS
Command $CHS<CR>
Response $CHS1,1,1,1OK<CRLF>
6.4.7

Channel Transmit (CHT)

Specifies the channels to be transmitted.
(0 = Do not transmit channel, 1 = Transmit channel)
CHT
Command For example $CHT1,1,0,0<CR>
Response $CHT1,1,0,0OK<CRLF>(Example: Channel 1 and 2 are transmitted)
Request channel transmit
Command $CHT?<CR>
Response $CHT?1,1,0,0OK<CRLF>
6.4.8

Status (STS)

Reads all settings at once.
The individual parameters are separated by a semicolon. The structure of the respective res-
ponses corresponds to those of the individual requests.
STS
Command $STS<CR>
Response $STSSRAn;AVTn;AVNn;CHS...;CHT...;TRG.OK<CRLF>
6.4.9

Version (VER)

Requesting the current software version including date.
VER
Command $VER<CR>
Response $VERKSS6380;V0.9;25.02.2010OK<CRLF>
1) Always all 4 channels (differential, Capa, Eddy, temperature) are available. A mathematic
function can be activated the first three channels.
,
1
