2.2.3

KSS6380 Controller

The controller contains an oscillator and a signal conditioning electronics for the sensor. The
capacitive and eddy current part of the sensor are synchronized with each other.
Power Analog
supply output
LED Display
Green Target within the measuring range
Red Target outside the measuring range
The controller is already tuned to the delivered sensor with connecting cable at the factory.
The output signal can only be displayed externally.
i
Switch off the power supply of the controller, when plugging and removing connectors.
Sensor Ethernet LED
