ANHANG C
Anhang C Modbus-Registerkarte (XTC501)
Kompatibel mit XTC501 Firmware Version: V1:08
Addr Funktion
0 Modbus Instrument Address (ID)
1 Settings Register
2 Display Contrast / Brightness
Units Register
3
(Tempr, Pressure, Ext Sens, Param, etc)
5 Background gas in application
4 Chart Interval
6 Alarm 1 (Lo alarm) Set point
7 Alarm 2 (Hi alarm) Set point
8 Range Zero (Ch1 output zero)
9 Range Span (Ch1 output span)
10 CH1 comp coefficient 20 %
11 CH1 comp coefficient 40 %
12 CH1 comp coefficient 60 %
13 CH1 comp coefficient 80 %
14 CH1 comp coefficient 100 %
15 N2 VCOMP ADC (for ratio comp)
16 BACKG VCOMP ADC (for ratio comp)
17 BACKG ZERO (for zero offset value)
18 BACKG SPAN (for ratio gas value)
19 BACKG CAL VALUE (for ratio gas value)
20 CH2 Input (Ext Sensor) zero
21 CH2 Input (Ext Sensor) span
22 Main gas in application
23 Cell Tempr Set point
27 Alarm / NAMUR Configuration
24 PID Proportional Term
25 PID Integral Term
26 PID Derivative Term
27 Alarm / NAMUR Configuration
29 Field Cal Reference 1
30 Field Cal Actual 1
31 Field Cal Reference 2
34 Language
35 Bridge Pot Wiper Code
36 Gain Pot Wiper Code
37 Field Cal Actual 2
38 Cal Ref1
39 Cal Ref2
40 Cal Ref3
41 Cal Ref4
52
XTP501 & XTC501 Bedienungsanleitung
Access Bereiche/Auflösung
R/W
R/W
R/W 0...100 % / 0...100 %, 10 % steps
R/W See reg details
R/W
R/W 2...60 sec, in 2 sec intervals
Instrum range min
R/W
Instrum range max, 0.01
Instrum range min
R/W
Instrum range max, 0.01
R 0.00 to Range Span
R Range Zero to 100.00
R/W
R/W
R/W
R/W
R/W
R
R
R -10.00...10.00 %
R 0.00...100.00 %
R 0.00...100.00 %
R/W See reg details
R/W See reg details
R/W
R
R/W See reg details
R
R
R
R/W See Reg Details
Instrum range min to Instrum range
R/W
max + 20 % of range, 0.01
R/W -199.99...199.99
Instrum range min to Instrum range
R/W
max + 20 % of range, 0.01
R/W
R
R
R/W -199.99...199.99
R
R
R
R
1...127
0...65535
0...23
0.50...2.00
0.50...2.00
0.50...2.00
0.50...2.00
0.50...2.00
0...8191
0...8191
0...23
40...70 C
1...20000
1...500
1...100
0...15
0...1023
0...1023
0.00...100.00
0.00...100.00
0.00...100.00
0.00...100.00
99976 Ausgabe 1, Mai 2021
Typ
A
B
C
D
A
A
G
G
G
G
G
G
G
G
G
A
A
G
G
G
F
F
A
A
L
A
A
A
L
G
G
G
A
A
A
G
G
G
G
G
