ATTENTION
The light flashes until the vacuum reaches –0.6 bar. The lifting device is ready for operation.
For details on switching it off, see chapter 7.1.

Starting with the pull cord (if the battery is empty, for example)

1. Pull on the starter handle
lightly until you feel
resistance.
2. Pull hard on the starter
handle.
3. Gently let the starter handle
return.

Handling a load

Lifting the load – applying suction
WARNING
37
Vacuum pump running in idle
Damage to the vacuum pump
►
When the motor is running in idle without a load, press both red RELEASE LOAD
buttons simultaneously. This closes the system from the pump to the valve and
evacuates the vacuum reservoir.
Risk of injury due to uncontrolled gripper movements
►
Always grip the load at its center of gravity.
►
The load must be loose.
►
The load must not adhere to anything.
►
The load must not be tilted.
►
Do not lift the load at an angle.

Starter handle

OPERATION
