Setting the lifting device down on the support feet / wheel set

Device (SH-3500-B) only with mountede suction plate
43
1. Push each locking lever to the right to unlock
it and pull the support foot out a few
millimeters.
2. Once both locking levers are unlocked, pull
the support foot all the way out.
3. Rotate the parking foot 180 degrees.
4. Push the support foot back into its guide
rails until it snaps in on both sides.
5. Repeat steps one through four on the other
side.
The lifting device may now be set down on the
parking feet.
Device with suction plate and wheel set
STORAGE
