Gripping range adjustment

5 Gripping range adjustment
5.1

Gripping range for bottom and intermediate parts (NW 550)

When gripping bottom or intermediate parts (see Fig. 2 or 3), the movable gripper arm must be set to
the smaller gripping area (A) (see Fig. 1)
Be careful when adjusting the gripping
range. Risk of injury to the hands!
54000035
Fig. 2
12 / 21
A
Fig. 3
Fig. 1
