A red or grey circle with a diagonal bar,
possibly with a black graphical symbol,
indicates that an action must not be taken
or must be stopped.
If these instructions are not observed, it
may result in malfunction or damage to the
equipment.
Tips and advice that make the work easier.

1.3 Target group

These installation and operating instructions are
intended for professional installers.

2. Product introduction

2.1 Product description

The AP80-100 pumps are a range of vortex and
single-channel (1-channel) impeller pumps designed
for pumping sewage, effluents, sludge and surface
water.
6
5
AP80 pump
Position Description
1 Lifing bracket
2 Stator housing
3 Nameplate
4 Pump housing
5 Outlet
6 Cable plug
6

2.1.1 Pumped liquids

The pumps must not be used for
pumping combustible, flammable, or
corrosive liquids.
The pumps are designed for transferring the following
liquids:
• sewage
• drainage and surface water
• sludge with minimal dry-solids content
• effluent.

2.1.2 Intended use

These pumps are designed for pumping sewage and
wastewater in a wide range of private and industrial
applications.
1
2
3
4
