10. Technical data

Maximum
solids size
[mm]
AP80 (1.3 kW)
AP80 (2.6 kW) 80
AP80 (2.0 kW)
AP100 (2.9 kW) 100

10.1 Operating conditions

Operating
S1
mode
0-40 °C. For short periods, a
Liquid
temperature of up to 60 °C is
temperature
allowed.
Maximum
density of the 1040 kg/m³
medium
pH 6 – 11
Maximum
installation 20 m
depth
Operating
6 bar
pressure
Regular cable
10 m
length
Maximum
15
starts per hour
The sound pressure level of the pumps is
lower than the limiting values stated in the
EC Council directive 2006/42/EC relating
to machinery.
Shaft seal
Impeller
type
Motor side
1-channel
Vortex SIC / SIC
1-channel

10.2 Weights

Type (kW)
AP80.80.13.3.1.28 (1.3)
AP80.80.13.3.1.30 (1.3)
AP80.80.100.13.3.1.28 (1.3)
AP80.80.100.13.3.1.30 (1.3)
AP80.80.26.3.V (2.6)
AP80.80.20.3.V (2.0)
AP100.100.29.3.1 (2.9)

10.3 Electrical data

Power supply
Enclosure class
Insulation class

11. Disposing of the product

This product or parts of it must be disposed of in an
environmentally sound way.
1.
2.
Ball bearing types
Medium
Upper
side
Double row
SIC / SIC
angular
3 x 400 V 50 Hz
1 x 230 V 50 Hz
IP68
H (180°C)
Use the public or private waste collection service.
If this is not possible, contact the nearest
Grundfos company or service workshop.
Lower
Deep groove
Weight (kg)
74
66
104
19
