3.2 Controls
Fig. 14 Controls
1 Splint pin (activation backup)
2 Activation button
3 Magnetic carrier
4 Signal LED
EN
EN
Operating Manual: PX-1C - Smoke Alarm Device with Radio Link
5 Radio button
6 Smoke intake lamella
7 Testing / stop button
(smoke alarm device cover)
