With each newly activated smoke alarm
device with radio link, the connection
mode time span keeps increasing. It re-
mains approximately 10 minutes for all
devices for structuring the radio group.
en
Commissioning of more smoke alarm devices with
radio links, connection mode and other setting up
of a radio group
1. Please commission every new smoke
alarm device with radio link close to
the installation position planned for the
device and select a sequence that be-
gins with the rooms adjacent to the first
centrally positioned smoke alarm device
with radio link (master).
Continue with commissioning the other
smoke alarm devices with radio links
into the rooms that are adjacent to the
room in which a smoke alarm device wi-
th radio link has already been commis-
sioned as described below, or in a room
which is adjacent to a room that has the
activated master device.
For activating every other smoke alarm
device with radio link to be linked to this
radio group, remove the black activation
fuse from the red activation button first
(Illus. 1 point a).
Now press the red activation button
(Illus. 1 point a) of the device. This but-
ton must close when pressed with the
device's housing. A short audible signal
indicates that your smoke alarm device
with radio link is activated.
2. The installed radio LED now indicates
through a short yellow interval (Illus. 6
point b) that the device is looking for
a smoke alarm device with radio link
in which the master function is swit-
ched on.
Since all smoke alarm devices with radio
links have a signal forwarding function
(routing-repeating function), it is not re-
quired for the smoke alarm device with
radio link to directly reach the device
with the master function activated. The
