PRODUCT DESCRIPTION
The following are located on the top panel on the front side of the cabinet: outlet pressure gauge
(2), pressure regulator (1), power switch (5) and hour counter (3). The connector (24) is located in
the lower portion of the cabinet's rear panel. The compressed air outlet (15) with an internal G1/4"
thread is located on the upper portion of the cabinet. A hose bushing (24) is installed in order to
serve as a condensate drain. The compressor runs in automatic mode when the power switch (5)
on the cabinet is switched on.
The following are located on the rear of the cabinet: cooling fans (15) to exhaust hot air from the
cabinet through the hot air exhaust ventilation openings in the cabinet. The cooling fans switch on
when the temperature switch reaches 40 °C and run until the temperature inside the cabinet drops
below 32°C.
Risk of compressor overheating.
Make sure that there are no obstacles at the cooling air inlet into the cabinet
(around the bottom part of the cabinet) and at the hot air outlet on the top back
side of the cabinet.
If the compressor is placed on a soft floor, e.g. carpet, create space between the
base and the floor or the cabinet and the floor, e.g. underlay the footings with
hard pads to ensure sufficient cooling of the compressor.
Description to Figure 1:
1. Air pump
2. Air tank
3. Non-return valve
4. Pressure switch
5. Safety valve
6. Pressure gauge
7. Inlet filter
10/2019
8. Fan
9. Ball valve
10. Automatic condensate drain
11. Filter
12. Condensate collection vessel
13. Magnetic holder
14. Compressed air outlet
